CSH450A-8

CSH450A-8 Featured Image
  • CSH450A-8

Short Description:

Adapt to complex conditions: The intelligent control system can adapt to various complex conditions, achieving constant power control and reducing excessive consumption.

Widely applicable: Suitable for infrastructure projects such as mining, well drilling, and public facility construction.

Performance optimization: Through intelligent control, it provides high-performance and high-efficiency compressor capabilities.


Product Detail

Product Tags

Compressor technical specifications
Dual transformation Single
Free air delivery[m³/min] 12.5
Free air delivery[CFM] 450
Pressure[bar] 8
Pressure[psi] 116
Compressor oil[L] 26
Element LGIR
Engine specifications
Type YC4A130-H311
Power(kW) 96
Working and Idling Speed(rpm) 2200/1400
Number of Cylinders 4
Displacement (L) 4.837
Emission Levels(Standard) Stage III
Fuel Capacity(L) 180
Dimensions and weight
Weight(t) 2
Outlet*Quantity G1½×1 & G¾×1
Tire Size*Quantity Two Tires
Overall Dimensions(mm) 3326x2000x2113
Noise [dB(A)] 80±3
